Vikylin 12mp 8ch 8poe Nvr Kit Security Camera System

Vikylin 4K 8MP Ultra HD Full Color PoE Security IP Camera  8MP | With Mic | Full Color Night Vision | H.265+ | Human Vehicle Detection | IP67 💡 Tips:

• 📱 APP Available: VideoLink (iOS, Android), support download by QR code
• 🔍 Search Tool: AjDevTool (search device and change IP address)
• 💻 PC Client: LMS
• 🌐 Default IP: 192.168.1.110
• 👤 Username: admin
• 🔑 Password: 123456
• 🌐 The camera supports ONVIF protocol.

Key Features        Camera:

• 1/2.7" CMOS sensor
• 3840x2160 video output
• Ultra low illumination 0.01Lux
• Day/Night (ICR), AWB, 2D/3D-DNR, IR-CUT, Privacy Mask, Mirror
• D-WDR, Motion Detection
• H.265/H.264 dual-stream media server
• Easy-to-use P2P Cloud service
• Multi web browser, PC Client, mobile APP remote access
• RJ45 100mbps network port, IEEE802.3af PoE
• Lightning protection 4000V
• Strong water-proof housing, IP66
• 2 pcs warm light, Light distance 20-30 meters
• HD 2.8mm F1.0 lens
• Built-in Mic & PoE
• Human Detection, Vehicle Detection

       NVR:

• Up to 8-ch IP camera inputs
• Supports IP cameras with a resolution up to 12 MP
• H.265+/H.265/H.264 video formats
• Up to 1-ch 12 MP@30fps/1-ch 8MP@30fps/4-ch 4MP@30fps decoding capacity
• Up to 80 Mbps incoming bandwidth
• Professional and Reliability
• H.265+ compression effectively reduces the storage space by up to 75%
• HD Video Output
• Provide simultaneous HDMI and VGA outputs
• HDMI video output at up to 4K resolution
• Storage and Playback
• 1 SATA interface for HDD connection (up to 14 TB )
• Smart Function
• Support intelligent analysis
• Using proprietary cameras to achieve ANPR, fire detection, etc.
• Network & Ethernet Access
• 8 independent PoE network interfaces
• 1 self-adaptive 10/100 Mbps Ethernet interface
• Videolink & Ajdevtools for easy network management

Specifications

Camera

Image Sensor

1/2.7" CMOS Sensor

Effective Pixels

4K (3840x2160)

Electronic Shutter

AUTO, 1/25s ~ 1/10000s

Min. Illumination

[email protected](AGC ON), 0Lux IR on

Day/Night

Auto/Color/(B/W)/Timing

WDR

Digital WDR

White Balance

Auto/Manual

AGC/BLC/HLC

Support

DNR

2D/3D DNR

Other

Multi-lines OSD, Motion Detection, Privacy Mask, Mirror

Encode

Video Standard

H.264/H.265/ H.265+

Video Resolution

Main Stream:

15fps@4K(3840x2160)/25fps@6MP(3072x2048)/5MP(2592x1944), 30fps@4MP/3MP/1080P/720P

Sub stream: 30fps@D1/VGA/360P/CIF, etc.

Video Bitrates

64Kbps - 8Mbps, VBR/CBR

Audio Standard

G.711-u/G.711-a/AAC

Built-in Mic

Yes

Smart Event

Human Detection

Vehicle Detection

Motion Detection

IR Led

IR Led

2 pcs warm light

IR Distance

20-30 metes

Lens

Focal length

HD 2.8mm F1.0 lens

Network Services

Protocol

HTTP(S)/RTSP/RTMP/FTP/NFS/SMTP/DHCP/NTP, etc.

P2P

Yes

Web

IE , Firefox 32bit ESR, etc.

Media

CMS, Android, IOS

General

Network Port

1-RJ45, 100Mbps, PoE

Power Supply

PoE (default), 12 VDC ± 10%

Power Consumption

< 5 W

Operating Temp.

-30°C-(+60)°C, 10%-90%RH

      Video and Audio IP video input 8-ch Up to 12 MP resolution Incoming bandwidth 80 Mbps Outgoing bandwidth 80 Mbps HDMI output 1-ch, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1920 x 1080/50 Hz, 1440 x 900/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz, 1280 x 720/50 Hz, 1024 x 768/60 Hz     VGA output 1-ch, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1440 x 900/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz, 1280 x 720/50 Hz, 1024 x 768/60 Hz Video output mode HDMI/VGA simultaneous output CVBS output N/A Audio output 1-ch, RCA Audio input 1-ch, RCA Decoding Decoding format H.265+/H.265/H.264 Recording resolution 12MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF/QCIF Synchronous playback 8-ch Capability 1-ch@12 MP (30 fps)/1-ch@8 MP (30 fps)/4-ch@4MP(30 fps)/8-ch@D1(30 fps) Stream type Video, Video & Audio Audio compression G.711U/G.711A Network Network protocol TCP/IP, DHCP, IPv4, IPv6, NTP, RTSP HTTP, HTTPS Network interface 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface PoE Interface 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface Power ≤ 90 W Supported standard IEEE 802.3 af/at Auxiliary Interface SATA 1 SATA interface Capacity Up to 14 TB USB interface 2 × USB 2.0 General Power supply 52 VDC, 1.8 A Consumption ≤ 3 W (without HDD and PoE off) Working temperature -10 °C to 55 °C (14 °F to 131 °F) Working humidity 10% to 90% Dimension (W × D × H) 260 × 210 × 43 mm (10.2" × 8.3" × 1.7") Weight (without HDD) ≤ 1 kg (2.2 lb)   Why Choose Vikylin?
